Viewing Status and Statistics
177
DWC-1000 Wireless Controller User’s Guide
Table 7-31. Buttons on the ASSOCIATED CLIENT STATUS Page
Field
Description
Disassociate
Disassociates the selected client from the managed access point.
View Details
Shows associated client details.
View AP Details
Shows associated access point details.
View SSID Details
Lists the SSIDs of the networks that each wireless client associated with a managed access point
has used for WLAN access.
View VAP Details
Shows information about the VAPs on the managed access point that have associated wireless
clients.
View Neighbor AP Details
Shows information about access points that the client detects.
