Viewing Status and Statistics
181
DWC-1000 Wireless Controller User’s Guide
Table 7-34. Fields on the VAP ASSOCIATED CLIENT STATUS Page
Field
Description
BSSID
Ethernet MAC address for the managed access point VAP where this client is associated.
SSID
SSID for the managed access point VAP where this client is associated.
AP MAC Address
Base access point Ethernet MAC address for the managed access point.
Radio
Managed access point radio interface with which the client is associated and its configured
mode.
Client MAC Address
Ethernet address of the client station.
Client IP Address
IP address of the client station.
Table 7-35. Buttons on the VAP ASSOCIATED CLIENT STATUS Page
Field
Description
Disassociate
Disassociates the selected client from the managed access point.
Refresh
Updates the information on the page.
