D-Link DWC-1000 [178/246] Associated client ssid status

Viewing Status and Statistics

178

DWC-1000 Wireless Controller User’s Guide

Associated Client SSID Status

Path: STATUS > Wireless Client Info > Associated Clients > SSID Status

The SSID ASSOCIATED CLIENT STATUS page shows SSID information for the wireless

clients on the WLAN.

Table 7-32. Fields on the SSID ASSOCIATED CLIENT STATUS Page

Field

Description

SSID

Network on which the client is connected.

Client MAC Address

Ethernet address of the client station.
