DWC-1000 Wireless Controller User’s Guide

Table 8-3. DEFINED ADDRESSES Page Settings

Field

Description

Source Address Type

Name of the group. Choices are:

 IP Address = specifies a particular IP address.

 IP Network = specifies an entire IP network.

Network Address / IP Address

Enter the network or IP address.

Mask Length

Enter a subnet mask.
