GRAPHITE 58G210 [12/80] Operation settings

CONSTRUCTION AND USE

Drill is a battery powered tool. Drive consists of a DC commutator

motor with permanent magnets and planetary gear. Drill is designed

for screwing in and out screws and bolts in wood, metal, plastics and

ceramics, and for drilling holes in those materials. Cordless, battery-

powered power tools are especially useful for works in interior

furnishing, adaptation of premises etc.

Use the power tool according to the manufacturer’s instructions

only.

DESCRIPTION OF DRAWING PAGES

Below enumeration refers to the device elements depicted on the

drawing pages of this manual.

1. Quick-release chuck

2. Ring of the quick release chuck

3. Torque adjustment ring

4. Gear switch

5. Direction selector switch

6. Battery lock button

7. Battery

8. Switch

9. Battery level indicator (LED)

10. Lighting

11. LED diodes

12. Charging station

13. Charger

* Diﬀerences may appear between the product and drawing.

MEANING OF SYMBOLS

NOTE

WARNING

ASSEMBLY / SETTINGS

INFORMATION

EQUIPMENT AND ACCESSORIES

1. Battery - 2 pcs

2. Charger - 1 pce

3. Charging station - 1 pce

4. Driver bit - 1 pce

5. Soft bag - 1 pce

PREPARATION FOR OPERATION

REMOVING AND INSERTING THE BATTERY

• Set the direction selector switch (5) in middle position.

• Push battery lock buttons (6) and slide out the battery (7) (g. A).

• Insert charged battery (7) into the handle holder, you should hear

when the battery lock buttons (6) snap.

BATTERY CHARGING

Drill is supplied with partially charged battery. The battery should

be charged in ambient temperature between 4

C and 40

C. New

battery, or one that has not been used for a long time, will reach full

eﬃciency after approximately 3 to 5 charge/discharge cycles.

• Remove the battery (7) from the drill (g. A).

• Connect the charging station (12) to the charger (13).

• Connect the charger (13) to mains socket (230 V AC).

• Put the battery (7) inside the charging station (12) (g. B).

Once the battery has been placed in the charging station, LED

diodes (11) will light up on the charging station (12), diﬀerent

conﬁgurations are possible (see below).

• Green diode on – indicates voltage on the connector.

• Green and red diodes on simultaneously – (when the battery

is placed in the charging station) indicate that the charging is in

progress.

• Red diode turns o, green diode stays on – indicate the battery

is fully charged.

Batteries heat up very strongly during charging process. Do not

work just after charging has been nished, wait until the battery

cools down to room temperature. It will prevent battery damage.

BATTERY LEVEL INDICATION

Each pressing the switch button turns on battery level indication.

Drill features battery level indication (4 LED diodes) (9). To check

battery level status, press the switch button (8) (g. C). When all

diodes are lit, the battery level is high. When 2 diodes are on, the

battery is partially discharged. When only one diode is lit, the battery

is discharged and must be recharged.

SPINDLE BRAKE

Drill is equipped with electronic brake that stops the spindle

immediately after the switch button (8) is released. The brake

ensures precision when screwing or drilling and prevents free

spindle rotation after switching oﬀ.

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

Switching on – press the switch button (8).

Switching o – release the switch button (8).

Each time the switch button (8) is pressed, the LED diode (10) lights

up to illuminate the workplace.

ROTATIONAL SPEED CONTROL

Increase or reduce pressure on the switch button (8) to adjust

drilling or driving speed while operating. Speed adjustment allows

for a soft start, which prevents dill slipping when drilling holes in

gypsum or glaze, and allows for operation control when screwing

in and out.

OVERLOAD CLUTCH

Set the torque adjustment ring (3) in appropriate position to

permanently set overload clutch to deﬁned torque value. When the

set torque is reached, overload clutch disconnects automatically. It

prevents screwing screws too deep or damaging the drill.

TORQUE ADJUSTMENT

• Diﬀerent screws and materials require diﬀerent torque to be

applied.

• The bigger the number corresponding to given position, the

bigger is the torque (g. D).

• Set the torque adjustment ring (3) to appropriate torque value.

• Always start operation with low torque.

• Increase the torque gradually until obtaining desired results.

• Use higher settings to unscrew screws.

• When drilling, choose setting marked with the drill symbol. The

torque is the greatest with this setting.

• Knowledge how to choose appropriate torque setting comes with

practice.

Setting the torque adjustment ring in the drilling position

deactivates the overload clutch.

WORKING TOOL INSTALLATION

• Set the direction selector switch (5) in the middle position.

• By turning the ring of the quick release chuck (2) counter

clockwise (see mark on the ring) you can spread jaws enough to

insert drill or driver bit (g. E).

• To install working tool, turn the ring of the quick release chuck (2)

clockwise and tighten.
