English
23
CAUTION
○ When transporting or carrying the tool, do not grasp the
holder.
○ There is the danger of the holder slipping out of the base.
Grasp the handle instead of the holder.
17. Stopper for precision cutting … (Stopper and
holder are optional accessory)
The stopper facilitates continuous precision cutting in
lengths of 280 mm to 450 mm.
To install the stopper, attach it to the holder with the 6
mm knob bolt as shown in Fig. 26.
18. Confi rmation for use Crown molding vise, Crown
molding Stopper (L) and (R) (Optional accessory)
(1) Crown molding Stopper (L) and (R) (optional
accessories) allow easier cuts of crown molding without
tilting the saw blade. lnstall them in the base both-sides
side to be shown in Fig. 27. After inserting tighten the
6 mm knob bolts to secure the Crown molding Stoppers.
(2) The crown molding vise (B) (Optional accessory) can be
mounted on either the left fence (Fence (B)) or the right
fence (Fence (A)). lt can unite with the slope of the crown
molding and vice can be pressed down.
Then turn the upper knob, as necessary, to securely
attach the crown molding in position. To raise or lower
the vise assembly, fi rst loosen the 6 mm knob bolt.
After adjusting the height, fi rmly tighten the 6 mm wing
bolt; then turn the upper knob, as necessary, to securely
attach the the crown molding in position (Fig. 28).
Position crown molding with its WALL CONTACT EDGE
against the guide fence and its CEILING CONTACT
EDGE against the Crown molding Stoppers as shown in
Fig. 28. Adjust the Crown molding Stoppers according
to the size of the crown molding.
Tighten the 6 mm wing bolt to secure the Crown molding
Stoppers.
WARNING
Always fi rmly clamp or vise to secure the crown molding
to the fence; otherwise the crown molding might be
thrust from the table and cause bodily harm.
Do not bevel cutting. The main body or saw blade may
contact the sub fence, resulting in an injury.
CAUTION
Always confi rm that the motor head does not contact the
crown molding vise ass’y when it is lowered for cutting.
If there is any danger that it may do so, loosen the 6 mm
knob bolt and move the crown molding vise ass’y to a
position where it will not contact the saw blade.
19. Groove cutting procedures
Grooves in the workpiece can be cut by adjusting the
6 mm depth adjustment bolt (Fig. 29).
(1) Lower the motor head, and turn the 6 mm depth
adjustment bolt by hand. (Where the head of the 6 mm
depth adjustment bolt contacts the hinge.)
(2) Adjust to the desired cutting depth by setting the
distance between the saw blade and the surface of the
base. (Fig. 29)
NOTE
When cutting a single groove at either end of the
workpiece, remove the unneeded portion with a chisel.
20. Using the Light (Only Model C8FSHE / C8FSHE(S))
WARNING
○ Check to ascertain that the main unit and light are off
before plugging the cord into the power socket.
○ The light lens reaches high temperatures during and
immediately after use and should not be touched under
any circumstances.
Failure to observe this may result in burns.
CAUTION
○ Do not subject the light to strong impact.
Failure to observe this may result in damage to the light
or a reduced life span.
○ Only switch the light on when cutting.
○ Do not shine the light continuously into the eyes.
Failure to observe this may result in damage to the eyes.
○ Wipe all dirt that adheres to the light lens with a soft cloth
gently so that the light is not scratched or damaged.
Scratches on the light lens may result in less luminance.
○ The light switch is fi tted with an anti-dust cover. Make
sure that the switch cover is not scratched or otherwise
damaged.
○ There are cases in which shavings may enter the switch
and prevent the light from functioning.
(1) Insert the plug on the main unit into a power socket.
(2) Set the light switch into the upper position (ON) to light
it, and into the lower position (OFF) to switch it off . (See
Fig. 30)
(3) Move the light fi tting to the right and left to adjust the
lighting position.
21. Using the dust bag (Standard accessory) (Fig. 31)
(1) Connect the dust bag with the duct of power tool.
(2) When the dust bag has become full of sawdust, dust will
be blown out of the dust bag when the saw blade rotates.
Check the dust bag periodically and empty it before it
becomes full.
(3) During bevel and compound cutting, attach the dust bag
at the right angle to the base surface.
22. Connecting the dust extractor (Sold separately)
(Fig. 32)
Do not inhale the harmful dusts generated in cutting
operation.
The dust can endanger the health of yourself and
bystanders.
Use of dust extractor can reduce dust related hazards.
By connecting with dust extractor through adapter,
joint and dust collection adapter, most of dust can be
collected.
Connect the dust extractor with adapter.
(1) Connect in order of hose (id 38 mm × 3 m long) and
adapter (Dust extractor’s Standard accessory) joint
(Optional accessory) and dust collection adapter
(Optional accessory) with the duct of power tool.
Connection is done by pressing in the direction of the
arrow. (Fig. 32)
The dust collection adapter (Optional accessory) is fi xed
to the duct by a hose band. (Optional accessory)
MOUNTING AND DISMOUNTING SAW
BLADE
WARNING
To prevent an accident or personal injury, always turn off
the trigger switch and disconnect the power plug from
the receptacle before removing or installing a blade.
1. Mounting the saw blade (Fig. 33)
(1) Use the accessory 10 mm box wrench to loosen the 6
mm bolt fastening the spindle cover and then rotate the
spindle cover.
(2) Press in spindle lock and loosen bolt with 10 mm box
wrench.
Since the bolt is left-hand threaded, loosen by turning it
to the right.
NOTE
If the spindle lock cannot be easily pressed in to lock
the spindle, turn the bolt with 10 mm box wrench while
applying pressure on the spindle lock.
The saw blade spindle is locked when the spindle lock is
pressed inward.
(3) Remove the bolt and washer (D).
(4) Lift the lower guard and mount the saw blade.
WARNING
When mounting the saw blade, confi rm that the rotation
indicator mark on the saw blade and the rotation direction
of the gear case are properly matched.
0000Book_C8FSHE.indb 230000Book_C8FSHE.indb 23 2017/12/01 14:05:332017/12/01 14:05:33
