Troubleshooting ESIE-0302
3–38 Part 3 – Troubleshooting
3
1
3
4
5
Others The table below contains the other settings.
Code Function EUWAC5-10FZ Read/write
h1 Unit type 2 r/w
h5 Pump functional logic 1
h6 Cooling/heating input 0
h7 ON/OFF input 0
h8 Number of terminals 0
h9 Keyboard lock-up 1
ha Serial address 1
hb Remote control password 1
hv Second set of parameters 1
hd Logic inversion cooling/heating 1
hf Alarm relay state without alarm 1
h
G Software release version — r
hh Status of output 2 (heater or second compressor) 0 r/w
