ESIE-0302 Troubleshooting
Part 3 – Troubleshooting 3–37
33
4
5
1
Anti-freeze and
supporting heaters
The table below contains the settings of the anti-freeze and the supporting heaters.
Alarm The table below contains the settings of the alarm.
Code Function EUWAC5-10FZ Read/write
a1 Anti-freeze alarm set point Standard 2.5˚C r/w
ZL option -11.5˚C
ZH option -6.5˚C
a2 Anti-freeze alarm hysteresis 5˚C
a3 Bypass time for anti-freeze alarm 0 s
a4 Anti-freeze heater set point Standard 4˚C
ZL option -10˚C
ZH option -5˚C
a5 Anti-freeze heater hysteresis 3˚C
a6 Supporting heaters probe 0
a7 Limit anti-freeze alarm set -15˚C
Code Function EUWAC5-10FZ Read/write
p1 Flow-start timer 20 s r/w
p2 Flow-stop timer 5 s
p3 LP bypass timer 60 s
p4 Buzzer ON time 1 min
p5 Reset of alarms 0
p8 Selection of digital input ID1 1
p9 Selection of digital input ID2 0
pa LP alarm when the compressor is OFF
pb High temperature alarm set 90˚C
pc High temperature alarm delayed at start-up 30 min
