Troubleshooting ESIE-0302
3–36 Part 3 – Troubleshooting
3
1
3
4
5
Regulator The table below contains the settings of the regulator.
Compressor The table below contains the settings of the compressor.
Fans The table below contains the settings of the fans.
Code Function EUWAC5-10FZ Read/write
r1 Cooling set point 12˚C r/w
r2 Cooling hysteresis 3˚C
ra Min. cooling set point Standard 7˚C
ZL option -7˚C
ZH option -2˚C
rb Max. cooling set point 25˚C
Code Function EUWAC5-10FZ Read/write
c1 Min. running time 0 s r/w
c2 Guard timer 6 x 10 s
c3 Anti-recycling timer 24 x 10 s
c6 Time-delay at start-up 0 s
c7 ON delay pump-compressor 15 s
c8 OFF delay pump-compressor 0 min
c9 Running hours compressor 1 — r
cb Maintenance threshold of c9 & cA 0 h x 100 r/w
Code Function EUWAC5-10FZ Read/write
f1 Are there any fans? 0 r/w
