ATXS20/25/35/42/50G2V1B SiBE04-808_B
93 Operation Manual
21
To use ON TIMER operation
•
1. Press “ON TIMER button”.
is displayed.
blinks.
2.
•
3. Press “ON TIMER button” again.
• The TIMER lamp lights up.
4. Press “CANCEL button”.
• The TIMER lamp goes off.
To combine ON TIMER and OFF TIMER
• A sample setting for combining the two timers is shown below.
ATTENTION
In the following cases, set the timer again.
• After a breaker has turned OFF.
• After a power failure.
• After replacing batteries in the remote controller.
(Example)
Combined
Check that the clock is correct. If not, set the
clock to the present time.
Press “TIMER Setting button”
until the time setting reaches the
point you like.
Every pressing of either button increases or
decreases the time setting by 10 minutes.
Holding down either button changes the
setting rapidly.
To cancel ON TIMER
operation
Present time: 11:00 p.m.
(The unit operating)
OFF TIMER at 0:00 a.m.
ON TIMER at 7:00 a.m.
3P207037-2D
