Troubleshooting SiBE04-808_B
103 Service Diagnosis
4. Troubleshooting
4.1 Error Codes and Description
★
: Displayed only when system-down occurs.
Error Codes Description
Reference
Page
System
00
Normal —
U0
★
Refrigerant shortage 140
U2
Low-voltage detection or over-voltage detection 143
U4
Signal transmission error (between indoor unit and outdoor unit) 110
UA
Unspecified voltage (between indoor unit and outdoor unit) 111
Indoor
Unit
A1
Indoor unit PCB abnormality 104
A5
Freeze-up protection control or heating peak-cut control 105
A6
Fan motor (DC motor) or related abnormality 107
C4
Indoor heat exchanger thermistor or related abnormality 109
C9
Room temperature thermistor or related abnormality 109
Outdoor
Unit
E1
Outdoor unit PCB abnormality 112
E5
★
OL activation (compressor overload) 114
E6
★
Compressor lock 115
E7
DC fan lock 116
E8
Input overcurrent detection 117
EA
Four way valve abnormality 118
F3
Discharge pipe temperature control 120
F6
High pressure control in cooling 122
H0
Compressor system sensor abnormality 124
H6
Position sensor abnormality 126
H8
DC voltage / current sensor abnormality (20/25/35/42 class) 129
CT or related abnormality (50 class) 130
H9
Outdoor temperature thermistor or related abnormality 132
J3
Discharge pipe thermistor or related abnormality 132
J6
Outdoor heat exchanger thermistor or related abnormality 132
L3
Electrical box temperature rise 134
L4
Radiation fin temperature rise 136
L5
Output overcurrent detection 138
P4
Radiation fin thermistor or related abnormality 132
U7
Signal transmission error on outdoor unit PCB (50 class only) 145
