SiBE04-808_B Control Specification
Function and Control 52
RK(X)S20-35G2V1B9, ARXS20-35G3V1B
Limitation of current drooping and stop value according to the outdoor temperature
The current droops when outdoor temperature becomes higher than a certain level
(depending on the model).
20 class 25 class 35 class
Cooling Heating Cooling Heating Cooling Heating
A
(A) 9.25 9.25 9.25
B
(A) Normal mode 6.0 7.5 6.25 7.5 8.25
ECONO mode 3.25 3.25 3.25
C
(A) Normal mode 5.25 6.75 5.5 6.75 7.5
ECONO mode 2.5 2.5 2.5
