Daikin FTXS35G2V1B [207/319] Cut the clamps at 2 locations
![Daikin FTXS35G2V1B [207/319] Cut the clamps at 2 locations](/views2/1761734/page207/bgcf.png)
SiBE04-808_B Outdoor Unit - RK(X)S20-35G2V1B, ARXS20-35G2V1B
Removal Procedure 196
7
Disconnect the
connectors for the filter
PCB [HL3] [HN3].
8
Remove the wire
harness for standby
electricity saving.
9
Cut the clamps at
2 locations.
Step
Procedure Points
(R9344)
[HN3] [HL3]
(R9345)
Wire harness
(R9346)
