Outdoor Unit - RK(X)S20-35G2V1B9, ARXS20-35G3V1B SiBE04-808_B
225 Removal Procedure
7
Release the harness.
8
Cut the clamps at the 2
locations.
9
Disconnect the
connector for the filter
PCB [S10].
Step
Procedure Points
(R11859)
(R11860)
(R11861)
[S10]
