Outdoor Unit - RK(X)S20-35G2V1B9, ARXS20-35G3V1B SiBE04-808_B
215 Removal Procedure
4
Cut the clamp.
5
Disconnect the
connector for the fan
motor [S70].
6
Release the fan motor
lead wire from the hook.
Step
Procedure Points
(R11830)
(R11831)
[S70]
(R11832)
Fan motor
lead wire
