SiBE04-808_B Outdoor Unit - RK(X)S20-35G2V1B9, ARXS20-35G3V1B
Removal Procedure 234
4
Pull the sound blanket
(inner) out.
5
Pull the sound blanket
(bottom) out.
Step
Procedure Points
(R11887)
Sound blanket
(inner)
Sound blanket
(bottom)
(R11888)
