![Daikin FTXS35G2V1B [212/319] Lift and pull out the main pcb](/img/pdf.png)
Daikin FTXS35G2V1B [212/319] Lift and pull out the main pcb
![Daikin FTXS42G2V1B [212/319] Lift and pull out the main pcb](/views2/1761734/page212/bgd4.png)
Outdoor Unit - RK(X)S20-35G2V1B, ARXS20-35G2V1B SiBE04-808_B
201 Removal Procedure
4
Remove the 4 screws.
5
Unfasten the 3 hooks
on the upper side.
6
Lift and pull out the
main PCB.
Step
Procedure Points
(R9359)
Screws
(R9360)
(R9361)
