SiBE04-808_B Outdoor Unit - RK(X)S42G2V1B, ARXS42G2V1B
Removal Procedure 248
4
Release the earth wire
from the hook.
5
Remove the 2 screws
and detach the 1 clip to
remove the radiation
shield plate.
6
Cut off the 5 clamps
and disconnect the wire
harnesses.
Step
Procedure Points
(R8159)
(R12198)
Radiation shield plate
Clip
(R8161)
(R8162)
