Daikin FTXS35G2V1B [262/319] Remove the screw of the radiation fin
![Daikin FTXS25G2V1B [262/319] Remove the screw of the radiation fin](/views2/1761734/page262/bg106.png)
Outdoor Unit - RK(X)S42G2V1B, ARXS42G2V1B SiBE04-808_B
251 Removal Procedure
12
Remove the screw of
the radiation fin.
Step
Procedure Points
(R12214)
Radiation fin
(R8171)
