Outdoor Unit - RK(X)S42G2V1B, ARXS42G2V1B SiBE04-808_B
255 Removal Procedure
2
The figure shows the
arrangement of the fan
motor lead wire.
3
Remove the 1 screw of
the fan motor fixing
frame.
4
Remove the fan motor
fixing frame.
Step
Procedure Points
(R8185)
(R12202)
Fan motor
fixing frame
(R8187)
(R8188)
