Daikin FTXS35G2V1B [290/319] Refer to page 28 for detail
![Daikin FTXS25G2V1B [290/319] Refer to page 28 for detail](/views2/1761734/page290/bg122.png)
Outdoor Unit - RK(X)S50G2V1B, ARXS50G2V1B SiBE04-808_B
279 Removal Procedure
8
Remove the 3 screws
of the main PCB.
9
Unfasten the 4 hooks.
10
Lift up and remove the
main PCB.
Refer to page 28 for detail.
Step
Procedure Points
Main PCB
(R5287)
(R5288)
Hooks
Main PCB
(R5289)
