Specifications SiBE04-808_B
11 Specifications
50 Hz, 220 - 230 - 240 V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTXS25G2V1B FTXS35G2V1B
Outdoor Units
RXS25G2V1B9 RXS35G2V1B9
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.5 (1.3 ~ 3.2) 3.4 (1.3 ~ 4.7) 3.5 (1.4 ~ 4.0) 4.0 (1.4 ~ 5.2)
Btu/h 8,500 (4,400 ~ 10,900) 11,600 (4,400 ~ 16,000) 11,900 (4,800 ~ 13,600) 13,600 (4,800 ~ 17,700)
kcal/h 2,150 (1,120 ~ 2,750) 2,920 (1,120 ~ 4,040) 3,010 (1,200 ~ 3,440) 3,440 (1,200 ~ 4,470)
Moisture Removal L/h 1.2 — 1.9 —
Running Current (Rated) A 3.2 - 3.0 - 2.9 4.3 - 4.1 - 3.9 4.4 - 4.2 - 4.0 4.8 - 4.6 - 4.4
Power Consumption
Rated (Min. ~ Max.)
W 550 (320 ~ 810) 750 (310 ~ 1,290) 870 (350 ~ 1,190) 960 (340 ~ 1,460)
Power Factor % 78.1 - 79.7 - 79.0 79.3 - 79.5 - 80.1 89.9 - 90.1 - 90.6 90.9 - 90.7 - 90.9
COP (Rated) W/W 4.55 (4.06 ~ 3.95) 4.53 (4.19 ~ 3.64) 4.02 (4.00 ~ 3.96) 4.17 (4.12 ~ 3.56)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 20 20
Max. lnterunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Units FTXS25G2V1B FTXS35G2V1B
Front Panel Color White White
Airflow Rate
m³/min
(cfm)
H 9.1 (321) 9.8 (346) 10.4 (367) 10.6 (374)
M 7.1 (252) 7.9 (280) 7.7 (270) 8.5 (302)
L 5.2 (182) 6.2 (217) 4.8 (170) 6.4 (226)
SL 3.7 (130) 5.2 (183) 3.5 (125) 5.4 (191)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09 0.12 - 0.12 - 0.11 0.13 - 0.13 - 0.12
Power Consumption (Rated) W 18 - 18 - 18 21 - 21 - 21 26 - 26 - 26 28 - 28 - 28
Power Factor % 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2 98.5 - 94.2 - 98.5 97.9 - 93.6 - 97.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight kg 9 10
Gross Weight kg 13 13
Operation
Sound
H / M / L / SL dBA 38 / 32 / 25 / 22 39 / 34 / 28 / 25 42 / 34 / 26 / 23 42 / 36 / 29 / 26
Sound Power dBA 54 55 58 58
Outdoor Units RXS25G2V1B9 RXS35G2V1B9
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.00 1.20
Airflow Rate
m³/min
(cfm)
H 33.5 (1,183) 28.3 (999) 36.0 (1,272) 28.3 (999)
SL 30.1 (1,064) 25.6 (905) 30.1 (1,064) 25.6 (905)
Fan
Type Propeller Propeller
Motor Output W 23 23
Running Current (Rated) A 3.06 - 2.93 - 2.81 4.14 - 3.96 - 3.80 4.26 - 4.08 - 3.91 4.71 - 4.50 - 4.31
Power Consumption (Rated) W 532 - 532 - 532 729 - 729 - 729 844 - 844 - 844 932 - 932 - 932
Power Factor % 79.0 - 78.9 - 78.9 80.0 - 80.0 - 79.9 90.1 - 89.9 - 89.9 89.9 - 90.0 - 90.1
Starting Current A 4.3 4.8
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 612 × 906 × 364
Weight kg 34 34
Gross Weight kg 38 38
Operation
Sound
H / SL dBA 46 / 43 47 / 44 48 / 44 48 / 45
Sound Power H dBA 61 62 63 63
Drawing No. 3D066469 3D066470
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
