GW-20
REAR WINDOW DEFOGGER
ACTIVE TEST
Display Item List
Trouble Diagnoses Symptom Chart
BIS000N2
● Check that other systems using the signal of the following systems operate normally.
IGN ON SW “ON / OFF” Displays “IGN SW ON (ON) / OFF (OFF)” status determined with the ignition switch signal.
ENGINE STATUS
“STOP / STALL
/ RUN / CRA ”
Displays “Engine stop (STOP) / engine stall (STALL) / engine running (RUN) / engine
cranking (CRA) ” as judged from engine status.
Monitor item “Operation” Content
Test item Content
REAR DEFOGGER Gives a drive signal to the rear window defogger to activate it.
Symptom Diagnoses / service procedure Refer to page
Rear window defogger and door mirror defogger do not
operate. (With door mirror defogger)
1. Check BCM power supply and ground circuit. GW-21
2. Check IPDM E/R auto active test. PG-22
3. Check rear window defogger switch circuit (with
auto A/C).
GW-22
3. Check rear window defogger switch circuit (without
auto A/C).
GW-23
4. Check rear window defogger power supply circuit. GW-25
5. Replace IPDM E/ R. PG-37
Rear window defogger does not operated.
(without door mirror defogger)
1. Check BCM power supply and ground circuit. GW-21
2. Check IPDM E/R auto active test. PG-22
3. Check rear window defogger switch circuit (with
auto A/C).
GW-22
3. Check rear window defogger switch circuit (without
auto A/C).
GW-23
4. Check rear window defogger power supply circuit. GW-25
5. Check rear window defogger circuit. GW-26
6. Check filament. GW-30
7. Replace IPDM E/ R. PG-37
Rear window defogger does not operate but both of door
mirror defoggers operate. (With door mirror defogger)
1. Check rear window defogger circuit. GW-26
2. Check filament. GW-30
Both of door mirror defoggers do not operated but rear
window defogger operate. (With door mirror defogger)
1. Check door mirror defogger power supply circuit. GW-27
Driver side door mirror defogger does not operated.
(With door mirror defogger)
1. Check driver side door mirror defogger circuit. GW-28
Passenger side door mirror defogger does not operated.
(With door mirror defogger)
1. Check passenger side door mirror defogger circuit. GW-29
