POWER WINDOW SYSTEM
● through BCM terminal 78.
Ground is supplied
● to rear power window motor (RH or LH) terminal 1
● through rear power window switch (RH or LH) terminal 4 and 3
● through power window main switch terminal 5 (RH) or 3 (LH)
● through power window lock switch
● through power window main switch terminal 17
● through body ground M21 and M66.
Then, the motor raises the window until the switch is released.
Window Down
When the rear RH or LH switch in the power window main switch is operated in the down position,
Power is supplied
● to rear power window motor (RH or LH) terminal 1
● through rear power window switch (RH or LH) terminal 4 and 3
● through power window main switch terminal 5 (RH) or 3 (LH).
● through power window main switch terminal 10
● through BCM terminal 78.
Ground is supplied
● to rear power window motor (RH or LH) terminal 2
● through rear power window switch (RH or LH) terminal 5 and 2
● to power window main switch terminal 7 (RH) or 1 (LH)
● through power window lock switch
● through power window main switch terminal 17
● through body ground M21 and M66.
Then, the motor raises the window until the switch is released.
AUTO OPERATION
The power window AUTO feature enables the driver to open or close the window without holding the window
switch in the down or up position.
POWER WINDOW LOCK
The power window lock is designed to lock operation of all windows except for driver door window.
When power window lock switch is in LOCK position, ground of passenger and rear power window switches in
the power window main switch are disconnected. This prevents the power window motors from operating.
ANTI-PINCH SYSTEM
Power window main switch monitors the power window motor operation and the power window position (full
closed or other) for driver side power window by the signals from encoder and limit switch in front power win-
dow motor (driver side).
When power window main switch detects interruption during the following close operation,
● automatic close operation when ignition switch is in the “ON” position
power window main switch controls power window motor (driver side) for open and the power window will be
lowered about 150 mm (5.91 in).
INITIALIZATION
Perform the initialization when the following operations are performed or when the auto up operation is not
performed. Refer to GW-91, "
SYSTEM INITIALIZATION" .
● When the power supply to the power window main switch or power window motor is cut off by the removal
of battery terminal or the battery fuse is blown.
● Disconnection and connection of power window main switch harness connector.
● Removal and installation of regulator assembly.
● Removal and installation of motor from regulator assembly.
● Operation of regulator assembly as an independent unit.
