POWER WINDOW SYSTEM
GW-53
C
D
E
F
G
H
J
K
L
M
A
B
GW
Trouble Diagnosis Symptom Chart
BIS000UP
Make sure other systems using the signal of the following systems operate normally.
*1: With front power window
*2: With front & rear power window
Symptom Repair order Refer to page
None of the power windows can be operated using any switch.
1. Check BCM power supply and ground circuit GW-54
2. Check power window main switch power supply
and ground circuit
GW-55*
1
GW-56*
2
Driver side power window alone does not operated.
1. Check front power window motor (driver side)
circuit
GW-58
*
1
GW-60*
2
2. Replace power window main switch EI-20
Front passenger side power window alone does not operated.
1. Check front power window motor (passenger
side) circuit
GW-61
*
1
GW-65*
2
Rear RH side power window alone does not operated. 1. Check rear power window motor RH circuit GW-68
Rear LH side power window alone does not operated. 1. Check rear power window motor LH circuit GW-71
Anti-pinch system does not operate normally (driver side).
1. Door window sliding part malfunction
● A foreign material adheres to window glass or
glass run rubber
● Glass run rubber wear or deformation
● Sash is tilted too much, or not enough
—
2. Limit switch adjustment GW-91
3. Check limit switch circuit (driver side)
GW-75
*
1
GW-78*
2
4. Check encoder circuit (driver side)
GW-80
*
1
GW-85*
2
5. Replace power window main switch EI-20
Power window lock switch does not function. 1. Check power window lock switch GW-88
Auto operation does not operate but manual operates normally
(driver side).
1. Check encoder circuit (driver side)
GW-80
*
1
GW-85*
2
2. Replace power window main switch EI-20
