GW-4
PRECAUTIONS
● If an unreusable part is removed, replace it with a new one.
● Tighten bolts and nuts firmly to the specified torque.
● After re-assembly has been completed, make sure each part functions correctly.
● Remove stains in the following way.
Water-soluble stains:
Dip a soft cloth in warm water, and then squeeze it tightly. After wiping the stain, wipe with a soft dry cloth.
Oil stain:
Dissolve a synthetic detergent in warm water (density of 2 to 3% or less), dip the cloth, then clean off the stain
with the cloth. Next, dip the cloth in fresh water and squeeze it tightly. Then clean off the detergent completely.
Thenwipetheareawithasoftdrycloth.
● Do not use any organic solvent, such as thinner or benzine.
