Nissan Note [88/104] Check power window lock switch
![Nissan Note [88/104] Check power window lock switch](/views2/1789819/page88/bg58.png)
GW-88
POWER WINDOW SYSTEM
Check Power Window Lock Switch
BIS0014S
1. CHECK POWER WINDOW LOCK SIGNAL
Exchanges for a normal power window main switch, and check operation.
Does power window lock operate?
YES >> Replace power window main switch.
NO >> Check condition of harness and connector.
