POWER WINDOW SYSTEM
GW-37
C
D
E
F
G
H
J
K
L
M
A
B
GW
● through front power window switch (passenger side) terminal 4 and 3
● through power window main switch terminal 11 and 10
● through BCM terminal 78.
Ground is supplied
● to front power window motor (passenger side) terminal 2
● through front power window switch (passenger side) terminal 5 and 2
● to power window main switch terminal 8.
● through power window lock switch
● through power window main switch terminal 17
● through body ground M21 and M66.
Then, the motor raises the window until the switch is released.
REAR DOOR (RH OR LH) [REAR POWER WINDOW SWITCH (RH OR LH) OPERATION]
Window Up
When the rear power window switch (RH or LH) is operated in the up position,
Power is supplied
● to rear power window motor (RH or LH) terminal 2
● through rear power window switch (RH or LH) terminal 5 and 1
● through BCM terminal 78.
Ground is supplied
● to rear power window motor (RH or LH) terminal 1
● through rear power window switch (RH or LH) terminal 4 and 3
● through power window main switch terminal 5 (RH) or 3 (LH).
● through power window lock switch
● through power window main switch terminal 17
● through body ground M21 and M66.
Then, the motor raises the window until the switch is released.
Window Down
When the rear power window switch (RH or LH) is operated in the down position,
Power is supplied
● to rear power window motor (RH or LH) terminal 1
● through rear power window switch (RH or LH) terminal 4 and 1
● through BCM terminal 78.
Ground is supplied
● to rear power window motor (RH or LH) terminal 2
● through rear power window switch (RH or LH) terminal 5 and 2
● through power window main switch terminal 7 (RH) or 1 (LH).
● through power window lock switch
● through power window main switch terminal 17
● through body ground M21 and M66.
Then, the motor lowers the window until the switch is released.
REAR DOOR (RH OR LH) (POWER WINDOW MAIN SWITCH OPERATION)
Window Up
When the rear RH or LH switch in the power window main switch is operated in the up position,
Power is supplied
● to rear power window motor (RH or LH) terminal 2
● through rear power window switch (RH or LH) terminal 5 and 2
● through power window main switch terminal 7 (RH) or 1 (LH).
● through power window main switch terminal 10
