POWER WINDOW SYSTEM
GW-35
C
D
E
F
G
H
J
K
L
M
A
B
GW
● Removal and installation of glass.
● Removal and installation of door glass run.
CAUTION:
The following operations are not performed under the condition that the initialization is not per-
formed yet.
● Auto up operation
System Description (With Front & Rear Power Window)
BIS000V0
Power is supplied at all times
● to BCM terminal 74 and 79
● through 40A fusible link (letter J , located in the fuse and fusible link box), and
● to power window main switch terminal 19
● through 40A fusible link (letter J , located in the fuse and fusible link box).
Ground is supplied at all times
● to BCM terminal 2 and 70
● through body grounds M21 and M66.
● to power window main switch terminal 17
● through body grounds M21 and M66.
With ignition switch in ON or START position, power is supplied
● to BCM terminal 24
● through 10A fuse [No. 5, located in the fuse block (J/B)], and
● to power window main switch terminal 10, front power window switch (passenger side) terminal 1 and
rear power window switch (RH and LH) terminal 1.
● trough BCM terminal 78
DRIVER DOOR
Window Up
Whenthedriversideswitchinthepowerwindowmainswitchisoperatedintheupposition,
Power is supplied
● to front power window motor (driver side) terminal 3
● through power window main switch terminal 16
● through CPU of power window main switch.
Ground is supplied
● to front power window motor (driver side) terminal 4
● through power window main switch terminal 12
● through CPU of power window main switch.
Then, the motor raises the window until the switch is released.
Window Down
Whenthedriversideswitchinthepowerwindowmainswitchisoperatedinthedownposition
Power is supplied
● to front power window motor (driver side) terminal 4
● through power window main switch terminal 12.
● through CPU of power window main switch.
Ground is supplied
● to front power window motor (driver side) terminal 3
● through power window main switch terminal 16.
● through CPU of power window main switch.
Then, the motor lowers the window until the switch is released.
