POWER WINDOW SYSTEM
GW-33
C
D
E
F
G
H
J
K
L
M
A
B
GW
● through CPU of power window main switch.
Then, the motor raises the window until the switch is released.
Window Down
Whenthedriversideswitchinthepowerwindowmainswitchisoperatedinthedownposition
Power is supplied
● to front power window motor (driver side) terminal 4
● through power window main switch terminal 7.
● through CPU of power window main switch.
Ground is supplied
● to front power window motor (driver side) terminal 3
● through power window main switch terminal 6 (LHD models) or 4 (RHD models).
● through CPU of power window main switch.
Then, the motor lowers the window until the switch is released.
PASSENGER DOOR [FRONT POWER WINDOW SWITCH (PASSENGER SIDE) OPERATION]
Window Up
When the front power window switch (passenger side) is operated in the up position,
Power is supplied
● to front power window motor (passenger side) terminal 2
● through front power window switch (passenger side) terminal 5 and 1
● through BCM terminal 78.
Ground is supplied
● to front power window motor (passenger side) terminal 1
● through front power window switch (passenger side) terminal 4 and 3
● through power window main switch terminal 9 (LHD models) or 5 (RHD models)
● through power window lock switch
● through power window main switch terminal 12
● through body ground M21 and M66.
Then, the motor raises the window until the switch is released.
Window Down
When the front power window switch (passenger side) is operated in the down position,
Power is supplied
● to front power window motor (passenger side) terminal 1
● through front power window switch (passenger side) terminal 4 and 1
● through BCM terminal 78.
Ground is supplied
● to front power window motor (passenger side) terminal 2
● through front power window switch (passenger side) terminal 5.
● through power window main switch terminal 2 (LHD models) or 13 (RHD models)
● through power window lock switch
● through power window main switch terminal 12
● through body ground M21 and M66.
Then, the motor lowers the window until the switch is released.
PASSENGERDOOR(POWERWINDOWMAINSWITCHOPERATION)
Window Up
When the passenger side switch in the power window main switch is operated in the up position
Power is supplied
● to front power window motor (passenger side) terminal 2
● through front power window switch (passenger side) terminal 5 and 2
