GW-36
POWER WINDOW SYSTEM
PASSENGER DOOR [FRONT POWER WINDOW SWITCH (PASSENGER SIDE) OPERATION]
Window Up
When the front power window switch (passenger side) is operated in the up position,
Power is supplied
● to front power window motor (passenger side) terminal 2
● through front power window switch (passenger side) terminal 5 and 1
● through BCM terminal 78.
Ground is supplied
● to front power window motor (passenger side) terminal 1
● through front power window switch (passenger side) terminal 4 and 3
● through power window main switch terminal 11
● through power window lock switch
● through power window main switch terminal 17
● through body ground M21 and M66.
Then, the motor raises the window until the switch is released.
Window Down
When the front power window switch (passenger side) is operated in the down position,
Power is supplied
● to front power window motor (passenger side) terminal 1
● through front power window switch (passenger side) terminal 4 and 1
● through BCM terminal 78.
Ground is supplied
● to front power window motor (passenger side) terminal 2
● through front power window switch (passenger side) terminal 5.
● through power window main switch terminal 8
● through power window lock switch
● through power window main switch terminal 17
● through body ground M21 and M66.
Then, the motor lowers the window until the switch is released.
PASSENGER DOOR (POWER WINDOW MAIN SWITCH OPERATION)
Window Up
When the passenger side switch in the power window main switch is operated in the up position
Power is supplied
● to front power window motor (passenger side) terminal 2
● through front power window switch (passenger side) terminal 5 and 2
● through power window main switch terminal 8 and 10
● through BCM terminal 78.
Ground is supplied
● to front power window motor (passenger side) terminal 1
● through front power window switch (passenger side) terminal 4 and 3
● through power window main switch terminal 11
● through power window lock switch
● through power window main switch terminal 17
● through body ground M21 and M66.
Then, the motor raises the window until the switch is released.
Window Down
When the passenger side switch in the power window main switch is operated in the down position,
Power is supplied
● to front power window motor (passenger side) terminal 1
