VTS WING II W100 EC [36/236] Technical information to the regulation eu no 327 2011

36

WING W100-200

WING E100-200

WING C100-200

EN

9. TECHNICAL INFORMATION TO THE REGULATION (EU) NO 327/2011

IMPLEMENTING DIRECTIVE 2009/125/EC

WING 100 WING 150 WING 200

1. 24.2% 24.0% 24.6%

8. 1-2-2801-0154 1-2-2801-0215 1-2-2801-0216

9. 0.41kW, 2826m³/h, 145Pa 0.48kW, 4239m³/h, 124Pa 0.68kW, 6006m³/h, 128Pa

Device disassembly should be performed and/or supervised by perperly qualied personnel having sufcient

knowledge. Contact a certied waste disposal company in your region. Explain what is to take place in terms of device

disassembly and subassembly securing. Disassemble the device using general procedures applied in mechanical

engineering.

4. Secure or isolate all elements which are powered and situated nearby.

To restore power supply, reverse the procedure.

In its dominant part, the device consists of of components made of steel, copper, aluminum and plastics, in varying

proportions (the rotor is made of SAN - styrene, acrylonitrile, structural material with the addition of 20% of glass

ber) and rubber (neoprene) sockets/bearing hubs. The components must be sorted before recycling according to the

following material categories: iron and steel, aluminum, copper, non-ferrous metals, e.g. winding (winding insulation

will be burnt in the course of copper recycling, insulation materials, electrical wires, electronic waste (condenser, etc.),

plastic elements (fan rotor, winding shields, etc.), rubber elements (neoprene). The same applies to textiles and cleaning

substances used to disassemble the components. Elements should be separated according to local regulations or by a

14. Fan housing, internal proles
