CC2000 User Manual
86
3. Fill in the fields according to the information provided in the table below:
4. When finished, click Next for the Connectivity page.
Field Information
Device
Information
Name: Provide a name to identify the device.
Model: The CC2000 recognizes the device model and fills in this
field automatically. It cannot be edited.
Description: If you wish to provide extra information to describe
the device, enter it here. This field is optional.
Department: For organizational purposes, you can establish
department categories (R&D, for example), and assign devices to
them (see Category Management on page 106). If you wish to
assign this device to a department, drop down the list of
departments (you have previously created), and click on the one
you want the device to belong to.
Location: For organizational purposes, you can establish location
categories (West Coast, for example), and assign devices to them
(see Category Management on page 106). If you wish to assign
this device to a location, drop down the list of locations (you have
previously created), and click on the one you want the device to
belong to.
Type: Use the drop-down menu to select the type of device it is.
Contact
Information
The name and telephone number of the device administrator.
These fields are optional.
Restrictions Hide IP Address from general users: As an added security
measure, if this feature is enabled, it prevents the device’s IP
address from appearing in the Device List when users log in via
their browser.
Hide MAC Address from general users: As an added security
measure, if this feature is enabled, it prevents the device’s MAC
address from appearing in the Device List when users log in via
their browser.
Power Control
Options
Set the Power Control Options as outlined below:
Check the box to enable confirmation for power operation
Check the box to enable delay for power operation, and enter the
Power on delay/ Power off delay fields in seconds.
