CC2000 User Manual
xiii
Appendix D, External Authentication Services, discusses the use of
authentication via external third-party services. It also provides examples of
configuring OpenLDAP for CC2000 authentication, and configuring RADIUS
for CC2000 authentication in a Linux environment.
Appendix E, SSO HTML Sample Codes, provides sample codes for the
Single Sign-On function.
Note:
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit or connected
devices.
ATEN regularly updates its product documentation for new features and
fixes. For an up-to-date CC2000 documentation, visit
http://www.aten.com/global/en/
Conventions
This manual uses the following conventions:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means
to press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦ Bullet lists provide information, but do not involve sequential
steps.
> Indicates selecting consecutive options (such as on a menu or
dialog box). For example, Start
>
Run means to open the Start
menu, and then select Run.
Indicates critical information.
