CC2000 User Manual
24
Post-Installation Setup
The CC2000 software comes with a default demo license that allows the server
to be a primary server with no secondaries and 16 nodes (all of which must be
on the same network as the server). For anything beyond this minimum, you
will need a purchased license key that allows secondary servers and additional
nodes.
Once the software is installed on the server, the next step is to specify whether
the server will be a Primary or Secondary.
If this server is going to be a Primary, insert the CC2000’s USB license
key into a USB port; log into the server (see Logging In, page 33); go to
the License page, and click Upgrade (see To upgrade the license, contact
your dealer to purchase a license key for the number of Secondaries and
nodes desired. After receiving your purchased USB license key, you can
upgrade the license of the CC2000 through one of the two following
methods: on page 199, for details). The number of Secondaries and nodes
allowed depends on your license key purchase.
Note: After upgrading the license, remove the key and place it somewhere
safe, since you will need it for future upgrades.
If this installation is going to be a secondary server, there is no need to
insert a license key – you simply need to register it with the primary. See
View Properties on page 222, for details.
