Aten CC2000 3.0 [251/353] Options

Chapter 8. Logs

237

Export

The Export tab offers two panel submenus: Logs in current page and All logs.



Logs in current page

Select Logs in current page to automatically download all logged event

records currently displayed on the device logs page.

Note: The amount of logs downloaded for Logs in current page is determined

by the Items per page option.



All logs

Select All logs to automatically download all logged event records from the

device logs.



To print out the Device Log list, select Print.

Note: Only the list that is displayed (all, or a filtered choice) is printed.

Options

The Options page provides settings of device log file’s Retention Policy. When

you select Options, a page similar to the one below appears:
