Chapter 1. Introduction
7
Browsers
Supported browsers for users logging into the CC2000 include the following:
Device Requirements
All ATEN/Altusen IP products must be at a firmware level that contains the CC
Management function, and the CC Management function must be enabled.
Download and install the latest version of the relevant firmware from our
Website, if necessary. For details on upgrading the firmware, see Update &
Restore on page 128.
Note: 1. Devices must be configured to communicate on the same port that as
the CC2000’s Device Port (see Device port, page 17).
2. For a list of supported devices, refer to the ATEN website.
Browser Version
IE 11 or later
Edge 42 or later
Chrome 56 or later
Firefox Windows 60 or later
Linux 60 or later
Sun 52 or later
Safari Mac 10 or later
Opera 57 or later
