Chapter 2. Server Installation and Utilities
27
CC2000 Secondary Servers
A complete CC2000 installation can comprise of 1 Primary and up to 31
secondary servers, located anywhere throughout the world. The primary server
is automated to be designated at the server where you upgraded the license of
your CC2000 software. See License, page 198, for details.
Once the primary server has been set, you can then register each of the other
CC2000 server as a Secondary with the Register function. See View
Properties, page 222, for details.
CC2000 Redundant Secondary Servers
To provide CC2000 server redundancy, at least a secondary CC2000 server
must be installed.
Should the primary server fail (due to network failure, CC2000 failure, etc.),
one of the secondary servers will act as the deputy primary server, maintaining
the connected devices and normal operation. However, administrators will not
be able to configure any of the settings until a primary server is present (fixed
or newly assigned).
Refer to Redundant Servers on page 221 on how you can appoint one of the
secondary servers as the redundant server.
