Firewalls

When several CC2000 servers are located behind separate firewalls, the

following service ports must be specified on the servers, and opened on the

firewall.

1. CC Port

Note: Each CC2000 server can have a different setting (8001 on Server 1;

8005 on Server 2, for example). But the port opened on the firewall

must correspond to the CC Port setting (8001 on Server 1’s firewall;

8005 on Server 2’s firewall).

2. The CC2000 primary server’s HTTPS port

3. The CC2000 proxy port (see CC2000 Proxy Function in the next section).

4. The CC2000 secondary server’s HTTPS port (Optional)

Note: 1. CC2000 Client Workstations can open web browser sessions to

CC2000 secondary servers within the same firewall.

Communication and access with other CC2000 servers on the

installation (outside of the firewall) takes place through the CC

and Proxy ports – therefore the HTTPS port isn’t necessary.

There is a drawback to doing this, however, in that you won’t be

able to perform device configuration on devices outside the

firewall.

2. You can open this port if you would like CC2000 Client

Workstations outside the firewall to be able to directly open a web

browser session to the secondary server inside the firewall.
