Aten CC2000 3.0 [195/353] Advanced

Chapter 7. System

181

3. Use the drop-down menu Protocol to select the protocol type from two

options: UDP and TCP.

If TCP is selected, you can check the Secure connection (SSL) checkbox

to enable secure connection (SSL).

4. Use the drop-down menu Message to select whether to log a short

message or a full message.

5. Use the drop-down menu Language to select the language you want the

message to be sent in.

6. When all your settings have been made, click Save.

Advanced

The Advanced page is used to inform select users of specified events that

occurred on the CC2000. When you select Advanced, a page similar to the one

below appears:
