Aten CC2000 3.0 [179/353] Kerberos

Chapter 6. User Accounts

165

2. Kerberos

Heading Information

KDC IP/Domain Get the IP/Domain from the Kerberos administrator.

KDC port Get the port information from the Kerberos administra-

tor.

REALM This is the domain over which Kerberos authentication

server has the authority to authenticate a user, host or

service.

Get the realm information from the Kerberos adminis-

trator.
