Aten CC2000 3.0 [182/353] Motp mobile one time password

CC2000 User Manual

168

6. MOTP (Mobile One-Time Password)

Heading Information

Server IP/Domain Get the information for the IP from the service administrator and

enter it here. Click Connect to test the connection.

Port Get the information for the Port from the service administrator

and enter it here. The default MOTP port is 1812.

Agent type Radius is automatically selected for you.

Authentication Type PAP is automatically selected for you.

Shared secret Enter the character string that you use for authentication with

the MOTP server. If unsure, get the most up to date information

for shared secret from the service administrator.
