CC2000 User Manual
100
Primary NIC – Specify the network protocol(s) for this NIC.
Additional NIC1 – Specify the network protocol(s) for this NIC
Additional NIC2 – Specify the network protocol(s) for this NIC.
Additional NIC3 – Specify the network protocol(s) for this NIC.
KVM settings – Select the access rights. Refer to the table below:
Serial settings – Select the network protocol(s) and the access rights (full
access and broadcast, full access and view only).
Power via PDU – Check/uncheck to enable/disable.
Rights Explanation
Full access and
VM (Read / Write)
The user can access the device (or specified ports on the
device), view the screen and can perform I/O operations on it
with the keyboard and mouse. The user also has read/write
rights to use the virtual media function.
Full access and
VM (Read Only)
The user can access the device (or specified ports on the
device), view the screen and can perform I/O operations on it
with the keyboard and mouse. The user also has read only
rights for the virtual media function.
Full access The user can access the device (or specified ports on the
device), view the screen and can perform I/O operations on it
with the keyboard and mouse.
View only The user can access the device (or specified ports on the
device), and view the screen, but cannot perform any opera-
tions on it.
No access The user has no access to the device (or specified ports on the
device). The device (or the specified ports) will not show up in
the Port Access Sidebar or List.
