CC2000 User Manual
162
Authentication Services
The CC2000 provides an internal Username / Password authentication service.
In addition, the CC2000 supports the following third party external
authentication servers: Active Directory, Kerberos, LDAP, RADIUS,
TACACS+, Windows NT Domain, MOTP* and Dual Authentication.
Note: 1. Authentication refers to determining the authenticity of the person
logging in; authorization refers to assigning permission to use the
device’s various functions.
2. These external servers provide authentication services only – they do
not provide authorization services. Authorization is provided through
the CC2000 management system.
3. The CC2000 supports Mobile One-Time Password (MOTP) servers
that can be used as 3rd party authentication servers to improve
security. For more information, see MOTP Settings, page 316, or visit
our web site: www.aten.com/CC2000-OTP
By adding an external authentication server to the CC2000 management
system (see page 163 for details), when you add a user account, you can select
the external authentication server from the list of authentication servers.
Note: For LDAP and Active Directory there is an additional authentication
method in which the user attempting to log in does not have an account
on the CC2000. In this case, the CC2000 checks the external server to
see if it contains an account with the username and password of the user
attempting to log in. If it does, the CC2000 checks to see if the user
belongs to a group that corresponds to a CC2000 domain group. If it
does, the CC2000 lets the user log in and assigns him the access rights
of the group. See Domain Groups tab, page 160, for details.
The Authentication Services submenu is shown below:
