Aten CC2000 3.0 [81/353] When you have finished click next the properties page appears

Chapter 5. Device Management

2. When you have finished, click Next. The Properties page appears.

Write community Key in the community value(s) if required by the SNMP

version.

Timeout Key in the server timeout value. The range is between 10

and 120.

Server Select the server to use.
