![Aten CC2000 3.0 [19/353] Requirements](/views2/1977513/page19/bg13.png)
Chapter 1. Introduction
5
Requirements
Server Requirements
Systems that the CC2000 server will be installed on should meet the following
requirements:
Hardware Requirements
Operating System Requirements
Small Installation
(< 100 devices)
Medium or Large
Installation
(> 100 devices)
CPU Intel Core i3 2+ GHz or above Intel Core i5 3+ GHz or above
Memory 4 GB or above 8 GB or above
Hard Drive 20 GB or above 40 GB or above
Ethernet At least 1 Ethernet adapter (100 Mbps or above)
— Giga LAN recommended
JRE 8 OpenJDK 8
Windows:
Server 2019
Server 2016
Server 2012
Server 2008
10
8
Windows:
Server 2019 x64
Server 2016 x64
10 x32/x64
Linux
Red Hat Enterprise Linux V. 4
Novell SUSE Enterprise Server 9
and 10
Ubuntu 15.10 x64
Ubuntu 15.10 x86
Debian 8.2 x64
Fedora 23 x64
Fedora 23 x86
OpenSUSE 13.1 x64
CentOS 7 x64
Linux
Ubuntu 16.04 x64
Ubuntu 20.04 x64
Fedora 32 x64
Redhat Enterprise 8.1 x64
CentOS 8.1 x64
