Chapter 7. System

185

SNMP

The SNMP menu offers two tab menu choices: SNMP Agent and SNMP

Manager. You can manage the access control of SNMP agent for SNMP

manager to query. The default SNMP page is SNMP Agent and it looks similar

to the one below:

SNMP Agent

The SNMP Agent page lets you set the CC2000’s agents and control access for

SNMP trap events, as detailed below:

To set the SNMP agents, do the following:

1. In the SNMP Port field, key in the port number(s) of the agent computer(s)

that will collect trap event information. The valid port range is 1–65535.

The default port is 161.
