Chapter 6. User Accounts
155
2. Enter a name, description and check the roles you want the new user type
to have.
Note: 1. The Name can be from 2–32 English alphanumeric characters,
but cannot contain the following: " ' \
2. The Description can be up to 256 Bytes.
3. Click Save to complete.
Edit User Type
1. Check the user type you wish to edit and click Edit.
Alternatively, you can move your cursor over the user type and click the
pencil icon.
2. Edit the name, description and check/uncheck the roles you want this user
type to have.
3. Click Save to complete.
Delete User Type
Check the user type and click Delete.
A confirmation message will pop up, click Ye s to delete the user type(s).
Note: You can only delete non-system user types.
