Chapter 11 Static Multicast Forward Setup
MES-3528 User’s Guide
114
connected to port 3. Figure 61 shows frames being forwarded to ports 2 and 3
within VLAN group 4.
Figure 59 No Static Multicast Forwarding
Figure 60 Static Multicast Forwarding to A Single Port
Figure 61 Static Multicast Forwarding to Multiple Ports
11.2 Configuring Static Multicast Forwarding
Use this screen to configure rules to forward specific multicast frames, such as
streaming or control frames, to specific port(s).
