Chapter 32 Access Control
MES-3528 User’s Guide
279
linkdown linkDown 1.3.6.1.6.3.1.1.5.3 This trap is sent when the
Ethernet link is down.
LinkDownEventOn 1.3.6.1.4.1.890.1.5.8.51.27
.2.1
This trap is sent when the
Ethernet link is down.
lldp LLDPRemoteTopologyCha
nge
1.0.8802.1.1.2.0.0.1 This trap is sent when the
LLDP (Link Layer Discovery
Protocol) remote topology
changes.
transceiver-
ddmi
transceiverddmiEventOn 1.3.6.1.4.1.890.1.5.8.51.27
.2.1
This trap is sent when one
of the device operating
parameters (such as
transceiver temperature,
laser bias current,
transmitted optical power,
received optical power and
transceiver supply voltage)
is above or below a factory
set normal range.
transceiverddmiEventCle
ar
1.3.6.1.4.1.890.1.5.8.51.27
.2.2
This trap is sent when all
device operating
parameters return to the
normal operating range.
Table 93 SNMP Interface Traps (continued)
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
Table 94 AAA Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
authenticati
on
authenticationFailure 1.3.6.1.6.3.1.1.5.5 This trap is sent when
authentication fails due to
incorrect user name and/or
password.
AuthenticationFailureEve
ntOn
1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when
authentication fails due to
incorrect user name and/or
password.
RADIUSNotReachableEve
ntOn
1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when there is
no response message from
the RADIUS server.
RADIUSNotReachableEve
ntClear
1.3.6.1.4.1.890.1.5.8.51.2
7.2.2
This trap is sent when the
RADIUS server can be
reached.
TACACS+NotReachableEv
entOn
1.3.6.1.4.1.890.1.5.8.51.2
7.2.1
This trap is sent when there is
no response message from
the TACACS+ server.
TACACS+NotReachableEv
entClear
1.3.6.1.4.1.890.1.5.8.51.2
7.2.2
This trap is sent when the
TACACS+ server can be
reached.
